The BZX12V Zener Diode is a highly reliable and essential component designed for voltage regulation and overvoltage protection in electronic circuits. With a nominal Zener voltage of 12V, this diode is ideal for creating stable voltage references and protecting sensitive components from excessive voltage. Its compact and durable design makes it suitable for a wide range of applications, including power supplies, voltage regulation circuits, and various electronic devices.
Key Features
- Zener Voltage: Nominal Zener voltage of 12V, providing a stable and precise reference voltage for various applications.
- Low Power Consumption: Designed to operate efficiently with a typical power dissipation of 500mW, making it suitable for low-power applications.
- High Reliability: Constructed with high-quality materials to ensure consistent performance and long-term reliability.
- Compact Size: Small form factor allows for easy integration into space-constrained circuit designs.
- Protection Capability: Ideal for protecting circuits from overvoltage by clamping the voltage to a safe 12V level.
- Wide Application Range: Versatile use in power supplies, voltage regulators, and other electronic circuits requiring voltage stabilization.
Specifications
- Zener Voltage (Vz): 12V ±5%
- Power Dissipation (Pd): 500mW
- Maximum Reverse Current (Ir): Typically 5µA at 1V reverse voltage
- Package Type: DO-35 or SMD (depending on specific part)
- Operating Temperature Range: -65°C to +150°C
- Tolerance: ±5% of Zener voltage
Applications
- Voltage Regulation: Provides a stable 12V reference voltage in power supply circuits, ensuring consistent performance of connected components.
- Circuit Protection: Acts as a safeguard against overvoltage, clamping the voltage to a safe 12V level to protect sensitive electronic components.
- Voltage Reference: Used in various circuits as a reliable 12V reference voltage source for accurate measurements and control.
- Signal Processing: Ideal for clipping and clamping in signal processing circuits, ensuring signals remain within safe voltage levels.
- Power Supplies: Commonly used in regulated power supplies to maintain a consistent output voltage, preventing damage to sensitive devices.
Benefits
- Stability: Ensures a stable and reliable 12V voltage reference, critical for accurate and consistent circuit operation.
- Protection: Protects sensitive components from potentially damaging overvoltage conditions, enhancing the longevity and durability of electronic devices.
- Versatility: Suitable for a broad range of applications, from simple voltage regulation tasks to complex circuit protection in advanced electronic systems.
- Compact Design: The small size allows for seamless integration into a variety of circuit designs, even in space-limited environments.
- Cost-Effective: Provides an economical solution for voltage regulation and protection needs in a wide array of electronic applications.
Why Choose the BZX12V Zener Diode?
The BZX12V Zener Diode is an indispensable component for anyone designing or working with electronic circuits that require stable voltage regulation and protection. Its reliable performance, ease of integration, and compact design make it a top choice for engineers, hobbyists, and professionals alike. Whether you’re working on power supplies, voltage regulation, or protecting sensitive circuitry, the BZX12V Zener Diode offers the performance and reliability you need.
Order your BZX12V Zener Diode today and ensure your electronic circuits are protected and stabilized with this high-quality, dependable component!
Package Includes:
10pcs of 12Volts BZX12V Zener Diode
